| Specification | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 1875 | 2063 |
| Power Rating (kW) | 1500 | 1650 |
| Frequency (Hz) | 50 | |
| Engine Model | 16M33G2000/5 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| Power Factor (PF) | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (Customizable) | |
| Fuel Tank Capacity Operating Time | ≥ 8 hours @ 75% load | |
| Model | BBDA2063 (Open Type) | BBDA2063S (Silent Type) |
|---|---|---|
| Length (L) mm | 5200 | ** |
| Width (W) mm | 2250 | ** |
| Height (H) mm | 2550 | ** |
| Tank Capacity (L) | 3450 | ** |
| Engine Model & Manufacturer | 16M33G2000/5 (BAUDOUIN) |
| Number of Cylinders / Valves | 16 / 64 |
| Cylinders Arrangement | Vee Configuration |
| Bore x Stroke (mm) | 150 x 185 |
| Displacement (L) | 52.3 |
| Thermodynamic Cycle | Diesel 4 Stroke |
| Mean Piston Speed (m/s) | 9.25 |
| BMEP @ ESP (Bar) | 27.53 |
| Cooling System | Liquid (water + 50% antifreeze) |
| Injection System | Direct |
| Fuel System | High Pressure Common Rail |
| Aspiration | Turbocharged and Aftercooled |
| Compression Ratio | 15:1 |
| Flywheel Housing | SAE 0 |
| Flywheel | 18" |
| Number of Teeth on Flywheel Ring Gear | 194 |
| Inertia of Flywheel (kg•m²) | 7.2 |
| Inertia of Crankshaft (kg•m²) | 10.1 |
| Emission Standard | N/A |
| Overall Dimensions with Radiator (L x W x H mm) | 3967 x 2237 x 2485 |
| Engine Dry Weight without Radiator (kg) | 5200 |
| Engine Dry Weight with Radiator (kg) | 6450 |
| Engine Wet Weight with Radiator (kg) | 7151 |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-454C |
| Alternator Rated Power | 1500kw/1875kva |
| Rated Voltage (V) | 230v/400v |
| Rated Frequency | 50hz |
| Connecting Type | 3 Phase and 4 Wire |
| Number of Bearings | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H Class |
| Telephone Influence Factor (TIF) | ≤50 |
| THF | ≤2% |
| Voltage Regulation, Steady State | ≤±1% |
| Transient State Voltage | ≤-15%~+20% |
| Engine | Alternator | Fuel System | Generating Set |
|---|---|---|---|
| Water Jacket Preheater | PMG excitation | 12/24 hour base tank | Deepsea, ComAp, Smartgen controllers |
| Oil Preheater | Space heater | Bunded fuel tank | Trailer |
| Oil manual pump | Winding temperature measuring | External fuel tank | Tools with the machine |
| Automatic fuel feeding | |||
| Switch between external tank and base tank (three-way valve) |
