| General Information | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 800 | 880 |
| Power Rating (kW) | 640 | 704 |
| Frequency (Hz) | 50 | |
| Engine Model | 4006-23TAG3A | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (Customizable) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Model | BP880 (Open Type) | BP880S (Silent Type) |
|---|---|---|
| Length (mm) | 4500 | 5600 |
| Width (mm) | 1800 | 2200 |
| Height (mm) | 2745 | 2550 |
| Tank Capacity (L) | 1472 | 1472 |
| Engine Model & Manufacturer | 4006-23TAG3A (PERKINS) |
| Number of Cylinders | 6 |
| Cylinder Arrangement | Vertical Inline |
| Cycle | Four Stroke |
| Aspiration | Turbocharged |
| Bore x Stroke | 160 x 190 mm |
| Cubic Capacity | 22.921 L |
| Compression Ratio | 13.6:1 |
| Prime Power/Speed | 705 kW/1500 rpm |
| Standby Power/Speed | 786 kW/1500 rpm |
| Cooling System | Force Water Cooling Cycle |
| Fuel Consumption (100% load) | 210 g/kWh @1500 rpm |
| Alternator Brand | BOBIG |
| Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-404C |
| Rated Power | 640kw/800kva |
| Rated Voltage | 230v/400v |
| Rated Frequency | 50hz |
| Connecting Type | 3 Phase and 4 W |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H class |
| Voltage Regulation, Steady State | ≤±1% |
